1200-hour Moist Carbon Dioxide-Sulfur Dioxide-air Test Chamber
Leave a Message
The SQCO-300 mixed gas corrosion test chamber utilizes sulfur dioxide (SO₂) and carbon dioxide (CO₂) to expedite the corrosion process of materials or products within a controlled temperature environment. It accurately simulates the extent of damage that materials or products endure over a specified duration. This test chamber is instrumental in comparing the quality of protective layers, assessing the corrosion resistance of component coatings, electronic parts, metal materials, electrical and electronic products, as well as industrial items in a mixed gas setting. The SQCO-300 chamber is capable of heating the test space to a predetermined temperature and maintaining it consistently. A precise volume of corrosive gases is introduced into the chamber, and upon reaching the standard concentration, the corrosion test on materials or products is initiated. Specification:
- Standards: UL 50E: 2015 Clause 8.8.2
- Dimensions: 300L (internal: 900*600*550mm, external: 1400*730*1550mm)
- Test Environment Conditions: The surrounding air should be free of high-concentration dust, corrosive, flammable, and explosive gases. Ambient temperature: 5~30℃, Relative humidity: ≤85%RH
- Temperature Range: 20℃~50℃ (Adjustable)
- Temperature Uniformity: ≤±2℃
- Temperature Fluctuation: ≤±0.5℃
- Temperature Resolution: 0.01℃
- Humidity Generation Method: Bottom water tank type (10ml/0.0003m³)
- Sulfur Dioxide Concentration: 0.1%~1% (volume percentage)
- Carbon Dioxide Concentration: 0.1%~1% (volume percentage)
- Gas Generation Method: Cylinder Method
- Concentration Measurement Method: Calculate volume ratio using formulas and measure with an anti-corrosion mass flow meter. The gas flow value is adjustable via the controller.
- Gas Flow: Adjustable using an anti-corrosion mass flow meter according to test requirements
- Test Time: ~9999 hours (Adjustable)
- Power: Single-phase 220V (110V available upon request)
