Hydraulic Vertical Impact Test System
Leave a Message
The LS-VS50 hydraulic vertical impact test system is an automated hydraulic lifting shock test apparatus employing a free-fall configuration. This equipment is utilized to quantify and evaluate the impact resistance characteristics of products or packaging, assessing functional reliability and structural integrity under shock conditions. The system executes conventional impact tests with half-sine, post-peak sawtooth, trapezoidal (square), and other waveform profiles. It accurately replicates shock waveforms and impact energy encountered in operational environments, facilitating system enhancement or packaging structure optimization.
Primary technical characteristics:
• Multi-guide pillar configuration ensuring smooth vertical motion with minimal acoustic emissions
• Monolithic cast table construction providing enhanced structural rigidity and reduced high-frequency noise transmission
• Hydraulic braking mechanism delivering elevated safety margins and prevention of secondary impact events
• Digital control system maintaining consistent impact parameter stability
• Integrated seismic isolation foundation reducing installation site requirements
Technical specifications:
| LISUN Model | LS-VS50 | LS-VS100 | LS-VS200 | LS-VS400 | LS-VS600 |
