The SUG255 Series Impulse Voltage Test Systems deliver high-precision transient voltage generation for insulation performance evaluation of electronic and electrical equipment. These systems generate standardized 1.2/50μs high-voltage impulse waveforms to simulate operational transient overvoltages, including lightning-induced surges and switching transients encountered in power distribution networks. This testing methodology assesses the insulation withstand capability of Equipment Under Test (EUT), identifies potential insulation deficiencies, and mitigates safety risks associated with insulation failure, such as leakage currents, short circuits, or equipment damage.
The SUG255 Series Transient Voltage Generators incorporate a large-format Android touchscreen interface with bilingual English and Chinese operation. These systems support electromagnetic compatibility (EMC) compliance testing across multiple industrial sectors, including LED lighting systems, medical equipment, power distribution infrastructure, industrial control systems, new energy charging stations, small to medium-sized motors, low-voltage electrical components, electrical metering devices, and household appliances.
Compliance Standards:
| Standard Reference | Standard Title |
| IEC 60255-5:2000 | Electrical Relays – Part 5: Insulation Coordination for Measuring Relays and Protection Equipment |
| IEC 60060-1:2010 |
