Multi-Function LED Clamp Set
Product No: CLAMP-2
Leave a Message
Description
The CLAMP-2 Multi-Function LED Clamp Set comprises three specialized LED test fixtures designed for photobiological safety testing in accordance with IEC 62471-2006 standards. (Note: Model CLAMP-2 is compatible with 0.3m integrating spheres; CLAMP-2A is compatible with 0.5m integrating spheres.)
Typical Applications (The CLAMP-2 facilitates testing of the following single LED types):
- Through-Hole LED Test Fixture
- Foot pitch: 7.5mm
- Compatible with halogen light sources, LED straw hat lamps, and other direct-inserted bulb configurations
- COB LED Test Fixture
- Maximum foot pitch: 24mm
- Designed for COB light sources with aluminum base plates
- Standardized installation process
- Multifunctional SMD LED Test Fixture
- Minimum pitch gap: 2mm × 5mm
- Maximum pitch gap: 6mm × 5mm
- Comprehensive compatibility with bottom-powered LED light sources including 3014, 2835, 5730, 1206, 0805, and similar LED bead configurations
