Electronic Ballast Production Line Compliance Tester
Product No: UI2000-OK
Leave a Message
Description
Electronic Ballast Production Line Compliance Tester Specifications:
- Eight-window display interface for simultaneous monitoring of input and output characteristics, facilitating comparative analysis and compliance verification.
- Frequency response capability extending to 1 MHz for comprehensive input current testing, ensuring precise evaluation of diverse electronic ballast configurations.
- High-speed testing architecture completes comprehensive input and output characteristic analysis within 60-second cycles, optimizing production line throughput.
- Portable design incorporating integrated microprocessor technology, specifically engineered for development laboratories and on-site production quality control applications.
- Comprehensive data output capabilities including parameter documentation, waveform visualization, and characteristic curves for input, output, and startup phases with integrated printing functionality.
- PC communication interface with specialized software supporting both Chinese and English language environments, operating within WINDOWS platform with intuitive human-machine interface for simplified operation.
Technical Parameters:
- Input Parameter Testing Capabilities
- Measurement parameters: voltage, current, power, power factor, grid frequency, total harmonic distortion, and harmonic components 0-39
- Data and curve documentation with printing capability
- Fundamental frequency range for voltage and current: 45Hz – 65Hz
- Narrowband measurement range: 45Hz – 5 kHz
- Broadband measurement range: 45Hz – 1MHz
- Voltage measurement range: 10 – 300V (RMS)
- Current measurement range: 10mA – 2A (RMS)
- Power measurement range: 0 – 600W
- Power factor measurement range: 0.000 – 1.000
- Measurement accuracy: Class 0.5
- Stable Output Parameter Testing Capabilities
- Measurement parameters: lamp voltage, lamp current, lamp power, filament current, imported cathodic current, crest factor, oscillatory frequency
- Data and curve documentation with printing capability
- Lamp voltage measurement range: 10 – 250V
- Lamp current, filament current, guided cathodic current measurement range: 10 – 800mA
- Lamp power measurement range: 1 – 160W
- Measurement accuracy: Class 2
- Startup Output Parameter Testing Capabilities
- Measurement parameters: pre-heating duration, dynamic characteristic curves and data for initial 0-5 minute period including lamp voltage, lamp current, filament current, guided cathodic current, crest values
- Lamp voltage measurement range during startup: 10 – 800V
- Lamp current, filament current, guided cathodic current measurement range: 10mA – 2A
- Measurement accuracy: Class 2
