Flame Retardant Performance Tester for Masks

WKS-1208 Masks Flame Retardant Performance Tester evaluates the combustion characteristics of masks upon flame exposure at a defined linear velocity. It is specifically designed for assessing the flame retardant properties of masks. Compliance with standards: GB 19083-2010, YY 0469-2011, GB 2626-2006, GB 19083-2003. Specifications include: Head mold automatic movement speed (60±5) mm/s, adjustable flame height of 40±4 mm, distance from flame to burner tip (20±2) mm, flame temperature at burner tip (800±50)℃, distance from burner top to mask lowest point (20±2) mm, burner height adjustment range: 30 mm, metal head mold wall thickness 2-3 mm, flame resistance. Dimensions: 980*550*350 mm. Continuous ignition and timing accuracy: 0-9999.9 s, ±0.1 s. Power supply: AC220V, 50Hz, 50W. Features include PLC touch screen control system for ease of operation and visualization. The metal human head mold fixture simulates actual mask use. Adjustable burner height with automatic timing positioning. Digital recording and display of burning and flame retardant times. Equipped with flame temperature measurement probe and indicator. Automatic control and ignition system. Burner interfaces for combustible gases like propane. Automatic timing and test data storage for easy report retrieval. Includes flame temperature measurement and detection thermocouple.
