IEC 60884-1 Clause 19 | IEC 60669-1 Clause 17 | IEC 60998-1 Clause 15 Temperature Rise Test System
Leave a Message
The WS-1 Temperature Rise Test System simulates standard operating voltage and current conditions for electrical accessories including household appliance plugs, socket-outlets, switches, and connectors. This system precisely measures temperature rise during sustained operation to evaluate thermal performance and structural integrity.
This integrated test platform combines programmable current regulation with multi-channel temperature sampling to monitor surface heating characteristics and electrode temperature profiles. The system facilitates verification of component dimensional compatibility and thermal management capabilities, ensuring compliance with international safety standards for electrical accessories.
Standards Compliance:
- IEC 60884-1:2022 – Plugs and socket-outlets for household and similar purposes – Part 1: General requirements
- IEC 60669-1:2017 – Switches for household and similar fixed electrical installations – Part 1: General requirements
- IEC 60998-1:2002 – Connectors for low-voltage circuits for household and similar purposes – Part 1: General requirements
- GB/T 2099.1-2022 – Household and similar electrical accessories – Plugs and socket-outlets – Part 1: General requirements
- GB 16915.1-2024 – Switches for household and similar fixed electrical installations – Part 1: General requirements
- GB/T 13140.1-2008 – Connecting devices for low-voltage circuits for household and similar purposes – Part 1: General requirements
Technical Specifications:
| Model | WS-1 | WS-2 | WS-3 |
|---|---|---|---|
| Test Stations | 8 | 8 | 8 |
| Test Current Range | 0-50A | 0-200A | 0-300A |
| Test Voltage | <3V | <3V | <3V |
| Programmable Timer | 0-9999s | 0-9999s | 0-9999s |
| Temperature Measurement | 0-1000°C (8×K-type thermocouples) | 0-1000°C (8×K-type thermocouples) | 0-1000°C (8×K-type thermocouples) |
| Standards Compliance | IEC 60884-1 Clause 19 (GB/T 2099.1 Clause 19) | IEC 60884-1 Clause 19 (GB/T 2099.1 Clause 19), IEC 60669-1 Clause 17 (GB 16915.1 Clause 17) | IEC 60884-1 Clause 19 (GB/T 2099.1 Clause 19), IEC 60669-1 Clause 17 (GB 16915.1 Clause 17), IEC 60998-1 Clause 15 (GB/T 13140.1 Clause 15) |
LISUN WS Series Temperature Rise Test System – Technical Support Documentation
The LISUN WS Series Temperature Rise Test System has been deployed in testing laboratories for over a decade. Our engineering support team has compiled comprehensive technical documentation addressing common operational questions and maintenance procedures.
