GB/T 14645-2014 Textile Flammability Testing Apparatus
Product No: LS-GBT14645
Leave a Message
Description
The LS-GBT14645 GB/T 14645-2014 Textile Flammability Testing Apparatus is engineered and manufactured in strict compliance with GB/T 14645-2014 requirements. This apparatus is specifically designed for conducting the 45° test method to determine the damaged area and ignition times of textile specimens. It delivers precise and repeatable test data essential for evaluating the flame retardant performance of textile products, ensuring compliance with relevant national and international standards including ASTM D1230.
Standards Compliance
| Standards No. | Standards Name |
|---|---|
| GB/T 14645-2014 | 纺织织物-燃烧性能-45°方向损毀面积和接焰次数测定 |
| ASTM D1230 | Standard Test Method for Flammability of Apparel Textiles |
Technical Specifications
| Index | Parameter |
|---|---|
| Dimension | 1200(L) × 500(W) × 700(H)mm |
| Power Supply | AC 220V, 50/60Hz, 5A |
| Applied Gas | ≥95% Propane (customer-supplied) |
| Weight | Approximately 50kg |
Key Features
- Heat-resistant glass observation door for real-time monitoring of test conditions.
- Stainless steel internal construction providing superior corrosion resistance and extended operational lifespan.
- Six ventilation ports integrated into cabinet top and sides to maintain proper airflow within the test chamber.
- Interchangeable sample holders accommodate various specimen types and testing protocols.
- Precision imported flow control valve enables accurate flame height adjustment.
- Imported pressure gauge and pressure regulating valve provide real-time gas pressure monitoring and stabilization.
Damaged Area Test Functionality
- Needle valve-controlled flame height adjustment with standard setting of 45±2mm.
- Integrated pressure regulation system ensures consistent gas supply for test repeatability.
- Optional planimeter accessory facilitates quantitative analysis of damaged area measurements.
Ignition Times Test Functionality
- Fixed 45° sample holder orientation conforms to standard test posture requirements.
- Digital timer with 0.1s accuracy supports automated timing functions for precise ignition duration measurement.
