IEC 60335-2-9 & IEC 60335-2-6 Induction Cooktop Test Vessel
Leave a Message
The LS-B69A Induction Cooktop Test Vessel is a precision-engineered testing instrument specifically designed for compliance verification of induction cooktops according to international safety standards. Its dimensional accuracy and material specifications are engineered to meet the exact requirements specified in relevant testing protocols. By simulating actual cooking vessel conditions, this test vessel provides standardized and repeatable testing parameters for induction cooktop performance evaluation.
This test vessel accommodates diverse testing requirements while maintaining structural integrity and consistent thermal conduction characteristics under specified operational conditions, ensuring all testing procedures satisfy regulatory compliance mandates. It enables laboratory technicians and quality engineers to accurately assess induction cooktop performance under controlled operating conditions, providing reliable validation data for product quality inspection and regulatory compliance certification. Suitable for comprehensive induction cooktop testing applications across multiple testing scenarios.
Standards Compliance:
- IEC 60335-2-9:2019 – Household and similar electrical appliances – Safety – Part 2-9: Particular requirements for electric cookers
- IEC 60335-2-6:2020 – Household and similar electrical appliances – Safety – Part 2-6: Particular requirements for electric hobs
- GB 4706.14-2020 – Safety of household and similar electrical appliances – Part 14: Particular requirements for electric cookers, cooking ranges, ovens and similar appliances
- GB 4706.22-2020 – Safety of household and similar electrical appliances – Part 22: Particular requirements for stationary electric cookers, cooking ranges, ovens and similar appliances
Technical Specifications:
| Model | LS-B69A (Aluminum Vessel) | LS-B69B (Iron Vessel) |
|---|---|---|
| Material | 6061 Aluminum Alloy | Low-carbon steel with maximum 0.08% carbon content |
| Dimensions (mm) | abc=Ф110×140×8 dh (height) δ (Bottom thickness)=Ф110×140×(2±0.5) abc=Ф145×140×8 dAH=Ф145×140×(2±0.5) abc=Ф180×140×9 dAH=Ф180×140×(3±0.5) abc=Ф220×120×10 dAH=Ф220×120×(3±0.5) abc=Ф300×100×10 dAH=Ф300×100×(5±0.5) |
Same dimensional specifications as LS-B69A |
| Side Wall Thickness (mm) | 2 | 2±0.5 |
| Container Bottom Maximum Concavity (mm) | 0.05, No protrusion permitted | C≦0.006d, No protrusion permitted |
| Configuration | Flat bottom with lid, cylindrical geometry | Cylindrical geometry without handle or protrusions, no lid |
| Test Liquid Capacity | According to Table 101 specifications | According to Table 101 specifications |
