LED Thermal and Electrical Performance Analyzer

Thermal parameter is the critical index for evaluating LED performance. Accurate measurement of thermal characteristics is essential for high-power LED applications to ensure reliability. These parameters impact optical, electrical, and lifespan attributes of LEDs. Thus, effective thermal management is crucial for manufacturers and users. This T5 LED Thermal Resistance and Electrical Performance Test Equipment is designed by LISUN. Measurements include: Junction temperature, K factor, Forward voltage, Forward current.

• Automatically records parameter changes over time
• Measurement functions include:
1. LED voltage K factor measurement
2. Monitoring of instantaneous junction temperature changes
3. High-resolution tracking of Junction temperature and Voltage relation over time
• Programmable thermal sink temperature settings
• User-friendly graphical interface for ease of operation
• Complies with relevant international standards

Specifications:

• Temperature control range: +10 ~ +105 ℃ (Ta = 25 ℃)
• Temperature control system accuracy: ± 0.5 ℃
• Maximum cooling power of the thermostat: 20W
• Dual temperature detection methods
