IEC 61032 Figure 11 Safety Test Probe with 0.5mm Wire

The IEC 61032 Figure 11 Test Probe 17 is a precision testing instrument featuring a 0.5mm-diameter test wire, engineered specifically to validate the inaccessibility of hazardous live components within electrical toys. It incorporates a thin, rigid metallic test wire designed to simulate small access apertures, coupled with an insulating nylon handle that provides secure, ergonomic grip during testing operations. Manufactured to comply with stringent international safety standards, this probe assesses whether live electrical elements in toys can be inadvertently contacted—a critical parameter for mitigating electric shock hazards. With lightweight construction and maneuverable design, it serves as an essential tool for compliance verification of electrical toys, aligning with global safety protocols including IEC 61032.

Specifications:
• Probe Type: IEC 61032 Test Probe 17 (test wire for electrical toy safety verification)
• Test Wire Diameter: 0.5 mm (precision dimension for simulating small access points)
• Test Wire Material: Metal (maintains rigidity for consistent test application, resistant to deformation)
• Handle Material: Nylon (electrically insulating, non-slip surface, durable for repeated laboratory use)
• Core Function: Verifies inaccessibility of hazardous live parts in electrical toys
• Applied Force: Negligible force (simulates accidental, minimal contact by users)
• Compliance: Conforms to IEC 61032 Figure 11 dimensional and performance specifications

Test Procedures:
• Inspect the test wire for physical damage (e.g., deformation, wear) and the handle for structural integrity.
• Power the electrical toy unit and ensure normal operational conditions.
• Grasp the nylon handle and direct the 0.5mm test wire toward potential access points on the toy enclosure.
• Determine whether the test wire makes contact with any hazardous live parts within the toy assembly.
• Document test results regarding accessibility to live components (pass/fail determination).

Applications:
• Safety compliance testing of battery-operated electrical toys (e.g., remote-controlled vehicles) according to IEC 61032 Figure 11 requirements.
