NF C 61-314 C7 Gauges for Pin Spacing Verification

NF C 61-314 C7 Gauges for Pin Spacing Verification are specialized tools compliant with the NF C 61-314 C7 standard, designed specifically for verifying the pin spacing of plugs and sockets. These gauges are engineered to meet strict requirements in electrical component testing, ensuring accuracy and consistency in pin spacing dimensions for electrical connection devices. As essential tools in quality control and compliance testing, they help manufacturers and testing institutions confirm conformity to industry standards, guaranteeing the safety and compatibility of electrical connections.

Specifications

• Complies with the NF C 61-314 C7 standard
• Precise dimensional tolerance for accurate pin spacing measurement
• Constructed from high-quality, wear-resistant materials for long-term use
• Ergonomic design for ease of operation during testing
• Calibrated to meet professional testing equipment accuracy requirements

Test Procedures

1. Prepare the gauge and the target plug or socket, ensuring both are free of debris and damage.
2. Position the gauge aligning with the pin area according to standard operation guidelines.
3. Gently insert or fit the gauge to check the fit and spacing between pins.
4. Observe and record whether the pin spacing meets the NF C 61-314 C7 standard through the gauge’s indicators.
5. Remove the gauge, clean and store it properly, and document the test data for traceability.

Applications

• Quality inspection of plug and socket products during manufacturing
• Compliance certification testing by third-party testing institutions
• Routine safety assessments of electrical connection devices
