Temperature Rise Test Fixture for Solid Pin Plugs

The LS-B67 temperature rise test clamping fixture serves as a specialized auxiliary apparatus engineered specifically for plug temperature rise evaluation. Fabricated from a proprietary brass alloy formulation, it maintains consistent electrical and thermal conductivity throughout testing procedures. The apparatus incorporates multiple copper blocks compatible with various plug dimensions, accompanied by dedicated clamping screws to ensure secure plug fixation. The pin aperture dimensions are engineered to strictly conform to applicable testing specifications, providing sufficient clearance for precise thermocouple positioning. The fixture includes a dedicated mounting board for integration with temperature rise test equipment, establishing a standardized testing environment for plug temperature rise assessment. This configuration ensures testing procedures meet regulatory specifications, facilitates acquisition of accurate temperature rise data, and provides robust support for safety performance evaluation of plug products.

Compliance Standards:
